Experimental Equipment

Cold Field Emission Gun Accelerating voltages: 60, 80 & 200 kV Probe (STEM)-Cs-Corrector; Image (TEM)-Cs-Corrector JED-2300 Energy-dispersive X-ray detector, 100mm2 Gatan GIF Quantum Gatan OneView (4k x 4k) & Gatan US1000 (2k x 2k) cameras [mehr]
Thermal field emission gun Resolution at 1 kV: 3 nm Resolution at 20 kV: 1 nm Accelerating voltage: 0.2 to 30 kV Magnification: 20-900000x [mehr]
Software Leica LasX High Resolution 10-Megapixel Camera 2D and 3D Measurements XY-Stage, Manual and Motorized Focus Drive (coarse/fine), Manual and Motorized Tilting Angle, Continuous Adjustment from  ± 60° Illumination: Transmitted and Reflective [mehr]
Software: Leica LasV3.8 High Resolution Leica Camera DFC 280 XY Stage Manual Manual Focus Drive (coarse/fine) Illumination: Transmitted and Reflective Polarisation Filter for Illumination [mehr]
Allows heating and/or biasing experiment inside the TEM. [mehr]
Allows performing experiments in liquids (static and flow conditions), additional heating and electrochemical packages are included. [mehr]
